PVC UV Sterilizer is a reliable and high-efficiency water disinfection system designed for medium to large flow applications. Made from corrosion-resistant PVC, it performs well in harsh environments such as aquaculture and wastewater treatment. Using 254nm UVC lamps, it effectively eliminates bacteria, viruses, and algae without chemicals. The multi-lamp modular design ensures strong and stable UV output for continuous operation. With flexible configurations and wide flow capacity options, it is ideal for industrial water treatment, recirculating systems, and fish farming, providing efficient and energy-saving UV sterilization.
1. Corrosion-Resistant PVC Structure
This PVC UV sterilizer is built with high-quality, corrosion-resistant material, making it ideal for harsh environments such as aquaculture and wastewater treatment. Compared to metal systems, it offers longer durability in chemical-rich water, ensuring reliable performance in industrial UV water treatment systems and aquaculture UV sterilization applications.
2. High-Efficiency 254nm UVC Disinfection
Equipped with powerful 254nm UVC lamps, the system achieves up to 99.9% sterilization efficiency by effectively eliminating bacteria, viruses, and algae. It is widely used in UV water sterilization systems, wastewater UV disinfection, and large-scale water purification processes.
3. Modular Multi-Lamp Design
The multi-lamp configuration allows flexible adjustment of UV power based on flow rate requirements. This design ensures strong and uniform UV exposure, making it suitable for high flow UV sterilizers and customized industrial UV disinfection solutions.
4. Wide Flow Capacity & Flexible Configuration
With flow capacity ranging from small to large systems (up to 100 m³/h), this PVC UV sterilizer system can be tailored to different project needs. It is ideal for recirculating water systems, fish farming, and large-scale water treatment applications.
5. Energy-Efficient & Chemical-Free Operation
This UV water treatment system provides safe, eco-friendly disinfection without chemicals, reducing operational costs and environmental impact. It ensures clean water quality while maintaining efficiency in sustainable water sterilization solutions.
Type | Flow
(M² /h) | UV Power
(W) | UVQty
(PCS) | Water
Inlet/Outlet
(mm) |
PUVC-1T15/T8 | 1 | 15 | 1 | 1/2" |
PUVC-2T30/T8 | 2 | 30 | 1 | 3/4" |
PUVC-3T30/T8 | 3 | 60 | 2 | 1" |
PUVC-6T30/T8 | 6 | 120 | 4 | 1"+1/2" |
PUVC-9T30T8 | 9 | 180 | 6 | 2" |
PUVC-12T30/T8 | 12 | 240 | 8 | 2" |
PUVC-15T30/T8 | 15 | 300 | 10 | 2" |
PUVC-05T16/T5 | 0.5 | 16 | 1 | 1/2" |
PUVC-08T25/T5 | 0.8 | 25 | 1 | 1/2" |
PUVC-2T36/T5 | 2 | 40 | 1 | 3/4" |
PUVC-4T36/T5 | 4 | 80 | 2 | 1" |
PUVC-8T36/T5 | 8 | 160 | 4 | 2" |
PUVC-12T36/T5 | 12 | 240 | 6 | 2" |
PUVC-20T36HO/T5 | 20 | 320 | 4 | 2" |
PUVC-25T36HO/T5 | 25 | 480 | 6 | 2+1/2" |
PUVC-30T36HO/T5 | 30 | 640 | 8 | 2+1/2" |
PUVC-20T64/T5 | 20 | 320 | 4 | 2" |
PUVC-25T64/T5 | 25 | 480 | 6 | 2+1/2" |
PUVC-30T64/T5 | 30 | 640 | 8 | 2+1/2" |
PUVC-30T64HO/T5 | 30 | 600 | 4 | 2+1/2" |
PUVC-60T64HO/T5 | 60 | 1200 | 8 | 3" |
PUVC-100T64HO/T5 | 100 | 1500 | 10 | 4" |
1. Aquaculture Systems
Used in fish farming to reduce bacteria and algae, improving water quality and supporting healthy aquatic growth.
2. Wastewater Treatment
Helps disinfect wastewater before discharge or reuse, ensuring safer and cleaner water.
3. Industrial Water Systems
Controls microbial growth in pipelines and cooling systems, maintaining stable operation.
4. Recirculating Systems (RAS)
Provides continuous water sterilization, reducing disease risks in recirculating environments.
5. Agricultural Irrigation
Disinfects irrigation water, helping reduce pathogens and improve crop safety.
1. How does this PVC UV sterilizer work?
It uses 254nm UVC lamps to disinfect water by destroying microorganisms’ DNA as water flows through the chamber. This process achieves up to 99.9% sterilization efficiency in UV water treatment systems without adding chemicals.
2. Is PVC material durable for long-term use?
Yes, high-quality PVC is highly resistant to corrosion and chemicals, making it ideal for harsh environments like aquaculture and wastewater treatment. It ensures long service life and stable performance in industrial UV sterilization systems.
3. What flow capacity can it handle?
The system supports a wide range of flow rates, typically up to 100 m³/h depending on the model. It can be customized to meet different large-scale water treatment requirements.
4. Does it require regular maintenance?
Maintenance is minimal. Regular cleaning of quartz sleeves and checking lamp performance helps maintain stable UV output and ensures efficient UV disinfection system operation.
5. Is UV treatment safe for water quality?
Yes, UV sterilization is chemical-free and does not affect water taste, odor, or composition, making it safe for aquaculture, industrial use, and wastewater applications.
